Hydrophilic urologic catheters with water sachet and urine bag

We present a new type of urologic catheters, hydrophilic coated, developed by GALMED in cooperation with Warsaw Polytechnic.
The hydrophilic layer after dipping in water swells up giving the catheter a slip, which facilitates the application in clear intermittent catheterisation (CIC).

The kits allow for catheterization
in places with difficult access to running water, as well as in travel and places without access to a bathroom.

Water sachets are equipped with clip which is our original design, allowing easy opening.

Nelaton with water sachet
Nelaton with water sachet and urine bag
Female Nelaton with water sachet
Female Nelaton with water sachet and urine bag
Female Nelaton short with water sachet
Tiemann with water sachet
Tiemann with water sachet and urine bag
Tapered tip with water sachet
Tapered tip with water sachet and urine bag
Soft-tip with water sachet
Soft-tip with water sachet and urine bag
Couvelaire with water sachet

Nelaton with water sachet

size	diameter	length	reference number
CH6	2,0 mm	400 mm	910604011
CH8	2,8 mm	400 mm	910804011
CH10	3,3 mm	400 mm	911004011
CH12	4,0 mm	400 mm	911204011
CH14	4,7 mm	400 mm	911404011
CH16	5,3 mm	400 mm	911604011
CH18	6,0 mm	400 mm	911804011

Nelaton with water sachet and urine bag

size	diameter	length	reference number
CH6	2,0 mm	400 mm	910604021
CH8	2,8 mm	400 mm	910804021
CH10	3,3 mm	400 mm	911004021
CH12	4,0 mm	400 mm	911204021
CH14	4,7 mm	400 mm	911404021
CH16	5,3 mm	400 mm	911604021
CH18	6,0 mm	400 mm	911804021

Female Nelaton with water sachet

size	diameter	length	reference number
CH6	2,0 mm	200 mm	910602012
CH8	2,8 mm	200 mm	910802012
CH10	3,3 mm	200 mm	911002012
CH12	4,0 mm	200 mm	911202012
CH14	4,7 mm	200 mm	911402012
CH16	5,3 mm	200 mm	911602012
CH18	6,0 mm	200 mm	911802012

Female Nelaton with water sachet and urine bag

size	diameter	length	reference number
CH6	2,0 mm	200 mm	910602022
CH8	2,8 mm	200 mm	910802022
CH10	3,3 mm	200 mm	911002022
CH12	4,0 mm	200 mm	911202022
CH14	4,7 mm	200 mm	911402022
CH16	5,3 mm	200 mm	911602022
CH18	6,0 mm	200 mm	911802022

Female Nelaton short with water sachet

size	diameter	length	reference number
CH6	2,0 mm	110 mm	910601114
CH8	2,8 mm	110 mm	910801114
CH10	3,3 mm	110 mm	911001114
CH12	4,0 mm	110 mm	911201114
CH14	4,7 mm	110 mm	911401114
CH16	5,3 mm	110 mm	911601114
CH18	6,0 mm	110 mm	911801114

Tiemann with water sachet

size	diameter	length	reference number
CH6	2,0 mm	400 mm	920604010
CH8	2,8 mm	400 mm	920804010
CH10	3,3 mm	400 mm	921004010
CH12	4,0 mm	400 mm	921204010
CH14	4,7 mm	400 mm	921404010
CH16	5,3 mm	400 mm	921604010
CH18	6,0 mm	400 mm	921804010

Tiemann with water sachet and urine bag

size	diameter	length	reference number
CH6	2,0 mm	400 mm	920604021
CH8	2,8 mm	400 mm	920804021
CH10	3,3 mm	400 mm	921004021
CH12	4,0 mm	400 mm	921204021
CH14	4,7 mm	400 mm	921404021
CH16	5,3 mm	400 mm	921604021
CH18	6,0 mm	400 mm	921804021

Tapered tip with water sachet

size	diameter	length	reference number
CH6	2,0 mm	400 mm	920604011
CH8	2,8 mm	400 mm	920804011
CH10	3,3 mm	400 mm	921004011
CH12	4,0 mm	400 mm	921204011
CH14	4,7 mm	400 mm	921404011
CH16	5,3 mm	400 mm	921604011
CH18	6,0 mm	400 mm	921804011

Tapered tip with water sachet and urine bag

size	diameter	length	reference number
CH6	2,0 mm	400 mm	920604021
CH8	2,8 mm	400 mm	920804021
CH10	3,3 mm	400 mm	921004021
CH12	4,0 mm	400 mm	921204021
CH14	4,7 mm	400 mm	921404021
CH16	5,3 mm	400 mm	921604021
CH18	6,0 mm	400 mm	921804021

Soft-tip with water sachet

size	diameter	length	reference number
CH6	2,0 mm	400 mm	920604012
CH8	2,8 mm	400 mm	920804012
CH10	3,3 mm	400 mm	921004012
CH12	4,0 mm	400 mm	921204012
CH14	4,7 mm	400 mm	921404012
CH16	5,3 mm	400 mm	921604012
CH18	6,0 mm	400 mm	921804012

Soft-tip with water sachet and urine bag

size	diameter	length	reference number
CH6	2,0 mm	400 mm	920604022
CH8	2,8 mm	400 mm	920804022
CH10	3,3 mm	400 mm	921004022
CH12	4,0 mm	400 mm	921204022
CH14	4,7 mm	400 mm	921404022
CH16	5,3 mm	400 mm	921604022
CH18	6,0 mm	400 mm	921804022

Couvelaire with water sachet

size	diameter	length	reference number
CH6	2,0 mm	400 mm	930604010
CH8	2,8 mm	400 mm	930804010
CH10	3,3 mm	400 mm	931004010
CH12	4,0 mm	400 mm	931204010
CH14	4,7 mm	400 mm	931404010
CH16	5,3 mm	400 mm	931604010
CH18	6,0 mm	400 mm	931804010
